SIO-CM300L type CNC Camshaft Milling Machine

Type SIO-CM300L
Main Specification 300mm
Mode Linear Guideway
Contact us
Detail

SIO-CM300L

CNC Cam Milling Machine (Linear Guide Rail)

Purpose of MachineTool:

SIO-CM300L CNC Cam MillingMachine (Linear Guide Rail) is a modern machine with high efficiency, highprecision and high rigidity. It was developed by SIO company.It is mainly used for half finishing or finishing camshaftslike S type brake camshafts. Machining cams become very fast and easy. Themachine can improve the production efficiency, machining accuracy and savingthe cost of human resources. It is the ideal processing machine for automobile,mechanic and other manufacturing industries.

General Description& Main Features:

Machine Bed

The machine bed made by high-grade cast is implemented instable horizontal framework in order to provide high accuracy and consistentrepeatability. The outstanding sturdy machine body is heat treated to relievestresses.

In line with the torsionresisting and sturdy construction, the linear guide rail slider is equippedwith ball screws which have high stiffness, accuracy and excellent dynamicperformance. Each of these units is driven via high precision servo motor,complete with position feedback system.

The work pieces are processingon the precision index head. Patents technology ensures the work piece has highdegreeofsymmetry and rapid positioning.

Milling Heads

The milling heads mounted onthe slides located. Adopt independent unit to ensure goodmovement precision, stiffness and stability. The drive of the milling heads isconducted via an AC vector motor and via a belt drive to the headstock inputpulley.

Hydraulic Unit

The hydraulic unit is a unitconnected to the chuck via generously dimensioned hydraulic piping. Thehydraulic oil is cooled using an oil heat exchanger.

Dual hydraulic chuck makes automatic clamping. The chuckhas internal blowing clearance system. Horizontal positioning with hydrauliclifting. Rapid back after installation.

Electrical control

Relevant parts of theelectrical control system of the machine are contained in a switch gearcabinet.

Operating Panel

The machine is equipped with acomputer numerical control system Siemens 808D with USB port.

Mobile manual pulse generator is equipped to easyoperate.

Accessory

Integrated automatic lubrication system makes themaintenance more reliable.

Configuration cooling pump and enclosed shield.

Equipped automatic chip removal device.

Optional Accessories (ExtraPrice):

NC system such as FANUC,SIEMENS, GSK or KND is available for your selection.
